While GraphQL queries perform read operations, mutations change the data. A mutation can create, update, or delete objects and fields. In REST terminology, queries operate like GET
requests, while mutations are similar to POST
, PUT
, and DELETE
.
Structure of a mutation
A mutation contains the following elements:
- The keyword
mutation
- An operation name for your local implementation. This name is required if you include variables. Otherwise, it is optional.
- The mutation name
- The input object or attributes. Most mutations require an input object that contains data or individual attributes for the application server to process. However, some mutations, such as
createEmptyCart
, do not require an input object. In this particular case, the authorization token passed with the request provides the needed context. - The output object, which specifies which data the mutation returns.
Example of mutation graphql
here in this example we are adding data in database using graphql mutation.
Step 1 :- You Create registration.php
file
<?php
/**
* @author KPYXAL
* @copyright Copyright (c) 2023
* @package Kpyxal_MutationGraphql
*/
\Magento\Framework\Component\ComponentRegistrar::register(
\Magento\Framework\Component\ComponentRegistrar::MODULE,
'Kpyxal_MutationGraphql',
__DIR__
);
Step 2 :- create etc/module.xml
file
<?xml version="1.0"?>
<!--
/**
* @author KPYXAL
* @copyright Copyright (c) 2023
* @package Kpyxal_MutationGraphql
*/
-->
<?xml version="1.0"?>
<config xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:noNamespaceSchemaLocation="urn:magento:framework:Module/etc/module.xsd">
<module name="Kpyxal_MutationGraphql" setup_version="2.0.0">
<sequence>
<module name="Magento_Backend"/>
<module name="Magento_GraphQl"/>
</sequence>
</module>
</config>
Step 3 :- GraphQL queries are declared under etc/schema.graphqls
type Mutation {
dataFormSubmit(input: FormInput!): FormOutput @resolver(class: "\\Kpyxal\\MutationGraphql\\Model\\Resolver\\FormDataSave") @doc(description:"Contact us form")
}
input FormInput {
name: String @doc(description: "Get Name")
number: String @doc(description: "Get Number")
email: String @doc(description: "Get Email")
password: String @doc(description: "Get Password")
gender: Int @doc(description: "Get Gender")
bdate: String @doc(description: "Get Birth Date")
}
type FormOutput {
success_message: String @doc(description: "Success Message")
}
Explanation of graphql :-
- type Mutation > declares Mutation operations of our module.
- dataFormSubmit > name of our Mutation.
- FormInput > it is input value and type.
- FormOutput > declares output message.
Step 4 :- Create Resolver Class Model/Resolver/FormDataSave.php
<?php
namespace Kpyxal\MutationGraphql\Model\Resolver;
use Magento\Framework\Exception\NoSuchEntityException;
use Magento\Framework\GraphQl\Config\Element\Field;
use Magento\Framework\GraphQl\Exception\GraphQlInputException;
use Magento\Framework\GraphQl\Exception\GraphQlNoSuchEntityException;
use Magento\Framework\GraphQl\Query\ResolverInterface;
use Magento\Framework\GraphQl\Schema\Type\ResolveInfo;
use Kpyxal\MutationGraphql\Api\TestRepositoryInterface;
use Kpyxal\MutationGraphql\Api\Data\TestInterface;
class FormDataSave implements ResolverInterface
{
private $contactusDataProvider;
/**
* @param
*/
public function __construct(
TestRepositoryInterface $testRepository,
TestInterface $testInterface
) {
$this->_testRepository=$testRepository;
$this->_testModel = $testInterface;
}
/**
* @inheritdoc
*/
public function resolve(
Field $field,
$context,
ResolveInfo $info,
array $value = null,
array $args = null
) {
$name = $args['input']['name'];
$number = $args['input']['number'];
$email = $args['input']['email'];
$password = $args['input']['password'];
$gender = $args['input']['gender'];
$bdate = $args['input']['bdate'];
$this->_testModel->setName($name);
$this->_testModel->setNumber($number);
$this->_testModel->setEmail($email);
$this->_testModel->setPassword($password);
$this->_testModel->setGender($gender);
$this->_testModel->setBdate($bdate);
$thanks_message = [];
try {
$this->_testRepository->save($this->_testModel);
$thanks_message['success_message']="Successfully Added";
} catch (CouldNotSaveException $e) {
$thanks_message['success_message']="Something went wrong.";
}
return $thanks_message;
}
}
Here in above resolver file we used:-
Kpyxal\MutationGraphql\Api\TestRepositoryInterface;
Kpyxal\MutationGraphql\Api\Data\TestInterface;
repository and interface file to save fields like email,name,number.
Step 6 :- Final step you check output. Run this query
mutation {
contactusFormSubmit(
input:{
name: "KPYXAL"
number: "+123456798"
email: "TEST@TEST.COM"
password: "pass@123"
gender: "1"
bdate: "28/08/2222"
}
){
success_message
}
}
Happy Coding ..! 😉
